post #346 of 355 Old 01-10-2016, 01:10 AM
Post Master General

laggy311's Avatar

Join Date: Jun 2013
Location: Phoenix
Posts: 5,543

I Ride: 2006 ZX6R, 1994 Honda V45 Magna, A Village Bicycle
Garage
Quote:
Originally Posted by spyros12 View Post
hello i have a full m4 system , kn air filter , block off plates .. and now Bazzaz is the next stop .. i want to have a Quickshifter too but i dont want the Traction control ..
I think i saw somewhere Z FI QS and said z fi +quickshifter in one ... is this thing exists? because i cant find it anywhere for my 09-12...
You can get the Base unit (Z-Fi) + QS4 Standalone quickshifter. 2 units.

Or pay a little more and get the Z-Fi + QS + Traction and just turn traction control off. One unit.

Here it is standing: atoms with consciousness; matter with curiosity. Stands at the sea, wonders at wondering: I, a universe of atoms an atom in the universe. - Richard Feynman
Quote:
Originally Posted by sbk1198 View Post
And look at those chicken strips too! What a squid!
Quote:
Originally Posted by Scorpi0 View Post
Easy answer bro....
Thug is native American
Quote:
Originally Posted by riverszzr View Post
I hope your fork seals start leaking..........
Quote:
Originally Posted by Scorpi0 View Post
Part it out. Claim it stolen
laggy311 is offline
Sponsored Links
Advertisement

post #347 of 355 Old 01-11-2016, 06:32 AM
Super Moderator

EvilTwin's Avatar

Join Date: Oct 2008
Location: Orange, CA
Posts: 5,195

I Ride: 03 ZX6R BMCNPR Frankentrackbike
Quote:
Originally Posted by spyros12 View Post
hello i have a full m4 system , kn air filter , block off plates .. and now Bazzaz is the next stop .. i want to have a Quickshifter too but i dont want the Traction control ..
I think i saw somewhere Z FI QS and said z fi +quickshifter in one ... is this thing exists? because i cant find it anywhere for my 09-12...
They discontiued the Z-Fi QS about 3 years ago, and dropped the price of the Z-Fi TC. You could always just turn the TC off by removing all the values in the TC map.

If you run the QS4 on top of a Z-Fi you end up with a lot of extra wiring and two control units.


If you want the breakdown on fuel management systems, take some time to read this thread.
For a walk through on pulling FI Codes, check out this thread.
Questions about Flashed ECUs vs. Fuel Controllers? Try this one.
Got a Z-Fi TC System? Read This to get an idea of how it works.
Here's a link to some Kawasaki Service Manuals that I've got hosted for everyone's use.
And please check out my blog for more sage advice and technical ramblings.
Some basics about braking here.
EvilTwin is offline
post #348 of 355 Old 02-26-2016, 11:02 AM
Team Green

honestSquid's Avatar

Join Date: Apr 2015
Location: make believe track
Posts: 182

I Ride: ZX6R (abs)
Garage
whats the big difference between the auto tune Bazzaz(Z-AFM) unit and non(Z-Fi)? why is the Z-Fi 50 bucks more? if both can be tuned on a dyno?
http://www.revzilla.com/motorcycle/b...uel-controller = non Auto Z-Fi why is this one more money?
http://www.revzilla.com/motorcycle/b...to-fuel-mapper = Auto tune. Z-AFM

Last edited by honestSquid; 02-27-2016 at 06:01 AM. Reason: To Reword the statement
honestSquid is offline
Sponsored Links
Advertisement

post #349 of 355 Old 02-26-2016, 11:44 AM
Super Moderator

EvilTwin's Avatar

Join Date: Oct 2008
Location: Orange, CA
Posts: 5,195

I Ride: 03 ZX6R BMCNPR Frankentrackbike
Quote:
Originally Posted by honestSquid View Post
whats the big difference between the auto tune Bazzaz unit and non? why is the non 50 bucks more? if both can be tuned on a dyno?
I have no idea what you're asking. All Z-Fi units can have a Z-AFM plugged into them and it's the Z-AFM that has the O2 sensor and gathers data to build a fuel map.


If you want the breakdown on fuel management systems, take some time to read this thread.
For a walk through on pulling FI Codes, check out this thread.
Questions about Flashed ECUs vs. Fuel Controllers? Try this one.
Got a Z-Fi TC System? Read This to get an idea of how it works.
Here's a link to some Kawasaki Service Manuals that I've got hosted for everyone's use.
And please check out my blog for more sage advice and technical ramblings.
Some basics about braking here.
EvilTwin is offline
post #350 of 355 Old 02-27-2016, 06:06 AM
Team Green

honestSquid's Avatar

Join Date: Apr 2015
Location: make believe track
Posts: 182

I Ride: ZX6R (abs)
Garage
Quote:
Originally Posted by EvilTwin View Post
I have no idea what you're asking. All Z-Fi units can have a Z-AFM plugged into them and it's the Z-AFM that has the O2 sensor and gathers data to build a fuel map.
I think I under stand why your confused about my question.
A) you need the Z-Fi period.
B) you add the Z-AFM as a additional piece?
I was under the impression that it was its own UNIT, not a added piece like the traction control etc.
honestSquid is offline
post #351 of 355 Old 02-27-2016, 02:53 PM
Super Moderator

EvilTwin's Avatar

Join Date: Oct 2008
Location: Orange, CA
Posts: 5,195

I Ride: 03 ZX6R BMCNPR Frankentrackbike
Ah, now I see where you were coming from. Yeah you have to have a Z-Fi to start with, if you want to do anything with fuel adjustment.


If you want the breakdown on fuel management systems, take some time to read this thread.
For a walk through on pulling FI Codes, check out this thread.
Questions about Flashed ECUs vs. Fuel Controllers? Try this one.
Got a Z-Fi TC System? Read This to get an idea of how it works.
Here's a link to some Kawasaki Service Manuals that I've got hosted for everyone's use.
And please check out my blog for more sage advice and technical ramblings.
Some basics about braking here.
EvilTwin is offline
post #352 of 355 Old 02-27-2016, 11:59 PM
Post Master General

laggy311's Avatar

Join Date: Jun 2013
Location: Phoenix
Posts: 5,543

I Ride: 2006 ZX6R, 1994 Honda V45 Magna, A Village Bicycle
Garage
Quote:
Originally Posted by honestSquid View Post
I think I under stand why your confused about my question.
A) you need the Z-Fi period.
B) you add the Z-AFM as a additional piece?
I was under the impression that it was its own UNIT, not a added piece like the traction control etc.
It is an add-on. It collects data but the software shows you the data in relation to what you set as ideal fuel ratios at different throttle positions and rpm ranges.

Even if you could view the z-afm's data standalone, you'd have nothing to do with it unless you could somehow hack the ECU and feed the data in.

Here it is standing: atoms with consciousness; matter with curiosity. Stands at the sea, wonders at wondering: I, a universe of atoms an atom in the universe. - Richard Feynman
Quote:
Originally Posted by sbk1198 View Post
And look at those chicken strips too! What a squid!
Quote:
Originally Posted by Scorpi0 View Post
Easy answer bro....
Thug is native American
Quote:
Originally Posted by riverszzr View Post
I hope your fork seals start leaking..........
Quote:
Originally Posted by Scorpi0 View Post
Part it out. Claim it stolen
laggy311 is offline
post #353 of 355 Old 02-28-2016, 03:52 PM
Super Moderator

EvilTwin's Avatar

Join Date: Oct 2008
Location: Orange, CA
Posts: 5,195

I Ride: 03 ZX6R BMCNPR Frankentrackbike
Quote:
Originally Posted by laggy311 View Post
It is an add-on. It collects data but the software shows you the data in relation to what you set as ideal fuel ratios at different throttle positions and rpm ranges.

Even if you could view the z-afm's data standalone, you'd have nothing to do with it unless you could somehow hack the ECU and feed the data in.
Well TECHNICALLY the Z-AFM just converts the O2 signal into something the Z-Fi recognizes and the Z-Fi processes and stores the data.
laggy311 likes this.


If you want the breakdown on fuel management systems, take some time to read this thread.
For a walk through on pulling FI Codes, check out this thread.
Questions about Flashed ECUs vs. Fuel Controllers? Try this one.
Got a Z-Fi TC System? Read This to get an idea of how it works.
Here's a link to some Kawasaki Service Manuals that I've got hosted for everyone's use.
And please check out my blog for more sage advice and technical ramblings.
Some basics about braking here.
EvilTwin is offline
post #354 of 355 Old 03-03-2016, 12:06 AM
Squid

Join Date: Mar 2016
Location: Chaingmai
Posts: 1
You won't be disappointed.
laggy311 likes this.

ติดตามบล็อกเกมสนุกมันส์ๆได้ที่นี่
ไก่ชนเงินล้าน
ไก่ชนล้านนา
ไก่ชนภาคใต้
nothingness is offline
post #355 of 355 Old 01-14-2017, 11:34 PM
Squid

WillOnTwo's Avatar

Join Date: Sep 2016
Location: Portland
Posts: 21

I Ride: 2013 Ninja ZX6R 636
Garage
Alright throwing my "noob" comment in to the pot. I'm about to order the bazazz z-fi system for my bike and then get it dynod afterwards. But in the mean time before I get it dynod would using a map that is somewhat close to my set up on the bazazz website be beneficial even though the map doesn't include the exact same exhaust system as me?


Sent from my iPhone using Tapatalk
WillOnTwo is offline
